Top Quality General Surgical Operating Tables of Medical Equipment

1 / 5

Top Quality General Surgical Operating Tables of Medical Equipment

Still deciding? Get samples of $ !

Request Sample

Send Inquiry

Product Description

Basic Info.

Model NO.

HH-T-5

Certification

CE, ISO13485

Group

Adult

LCD Display

Without LCD Display

Application

Orthopedic, Abdominal

Material

Steel

Feature

Disposable

Transport Package

Wooden Package

Specification

Tabletop length > 2100mm

Origin

China

HS Code

9402900000

★

Product Description

The overall lifting, front and rear tilt, left and right tilt, back lift, bed translation, and brake are all controlled by electric devices.
Head and leg plate folding are controlled by precision gas springs for smooth adjustment.
Constructed from medical-grade 304 stainless steel with a matte finish for modern aesthetics and easy cleaning.
Longitudinal movement capability allows for seamless use with C-arms for radiographic examinations and filming.
The tabletop is made of high-strength and X-ray transparent composite material (carbon fiber upgrade available) to meet clinical imaging needs.
Mattress features slow-rebound memory foam, ensuring comfort, even pressure distribution, and resistance to corrosion/chemicals.
Removable head and leg boards; leg boards can be manually rotated, abducted, and folded to provide medical staff with flexible surgical space.
Handheld manipulator offers smooth operation; optional foot controller available for enhanced convenience.
High-strength stainless steel bottom cover provides strong pressure resistance and anti-corrosion properties.
Mobile base equipped with high-quality wheels for flexible movement and reliable fixed positioning.
Built-in lumbar bridge facilitates gallbladder, kidney, and other specialized surgeries.
Equipped with a built-in battery to ensure uninterrupted operation during power outages.

⚙

Main Technical Parameters

Front and back tilt of the table	Front tilt ≥ 25°, back tilt ≥ 25°
Left and right tilt angle	Left tilt ≥ 20°, right tilt ≥ 20°
Back plate folding angle	Upward ≥ 75°, Downward ≥ 15°
Head plate folding angle	Upward ≥ 40°, Downward ≥ 90°
Leg plate folding angle	Upward ≥ 75°, Downward ≥ 15°, Extension ≥ 90°
Table surface Specification	Length ≥ 2100mm, Width ≥ 550mm
Minimum table height	≤ 750mm (Without mattress)
Waist plate rise	≥ 120mm
Translational stroke	≥ 300mm
Table lift range	≥ 300mm

📷

Detailed Photos

🏢

Company Profile

The enterprise was established in 2022. It is an innovative high-tech enterprise specializing in independent design, production, and sales of medical operating beds and other equipment. It is one of the enterprises that utilize aerospace high-tech carbon fiber composite materials in the production of medical equipment. The main product range includes multi-functional series of imaging operation beds, orthopedic imaging operation beds, spinal surgery imaging operation beds, urology imaging operation beds, microscopic neurosurgery imaging operation beds, interventional imaging operation beds, and X-ray diagnostic film beds.

✔

Certifications

Frequently Asked Questions

Q1: What materials are used in the construction of the operating table? A: The table is constructed from medical-grade 304 stainless steel with a high-strength, X-ray transparent composite material for the tabletop.

Q2: Can this operating table be used for X-ray imaging? A: Yes, the tabletop is X-ray transparent and supports longitudinal translation, making it ideal for use with C-arm imaging systems.

Q3: Does the table have emergency power support? A: Yes, the operating table is equipped with a built-in battery to ensure normal operation during power outages.

Q4: What types of surgeries is the HH-T-5 model suitable for? A: It is versatile for various procedures including orthopedic, abdominal, gallbladder, and kidney surgeries.

Q5: How is the adjustment of the table controlled? A: Most major movements like lifting and tilting are electric, while head and leg plates are adjusted via precision gas springs.

Q6: Is the mattress comfortable for long procedures? A: Yes, it uses slow-rebound memory foam that evenly distributes pressure and is easy to clean and disinfect.
