1
Single-beam dual-wavelength NDIR technology to ensure accuracy of analysis results.
2
Temperature, barometric pressure, and anesthetic agent compensations included.
3
Applicable to both intubated and non-intubated patients.
4
Suitable for adult, pediatric, and neonatal use.
5
Large 5.5 inch colored display with high resolution and adjustable brightness.
6
High-capacity Li-ion battery providing 7-8 hours of continuous battery life.
7
Equipped with large data storage space for clinical monitoring.
Frequently Asked Questions
What parameters does the ESAG model monitor?
The ESAG model monitors multiple vital parameters including Etco2, SpO2, Fico2, Respiratory Rate (Rr), Pulse Rate (Pr), and Anesthesia Gas (AG).
Does the EtCO2 sensor require manual calibration?
No, the device utilizes the latest generation of dual-channel NDIR technology which does not require manual calibration.
Is this device portable for mobile medical use?
Yes, the device weighs only 900g (including battery) and features a built-in Li-ion battery providing 7-8 hours of operation, making it ideal for mobile transport.
Can this monitor be used for neonatal patients?
Yes, the monitor is applicable to adult, pediatric, and neonatal patients, with specific accessories like infant nasal cannulas and airway adapters available.
What type of display technology is used?
It features a 5.5-inch 720p high-resolution colored display with adjustable brightness for clear visualization in different lighting conditions.
What certifications does this medical device hold?
The device is fully certified with CE, FDA, and ISO13485 standards, ensuring compliance with international medical quality requirements.
