Sy-F003 Colposcope Digital Imaging System Gynecology Colposcope

1 / 5

Sy-F003 Colposcope Digital Imaging System Gynecology Colposcope

Customization:	Available
Classification:	Imaging Diagnostic Equipment
Type:	Digital Imaging System

Send Inquiry

Product Description

Basic Specifications

Model NO.

SY-F003

Certification

CE, ISO13485

Package

Carton Box

Origin

China

Capacity

500 Sets/Month

SY-F003 Colposcope Digital Imaging System

✓

Imported color digital CCD with 480,000 pixels precision and 1-128x continuous magnification.

✓

High-power white LED lighting with 100,000 hours lifetime and superior color temperature.

✓

Advanced image halo filtering technology ensures high-definition clarity for clinical diagnosis.

✓

Super-large memory storage capable of managing up to 100,000 patient cases.

✓

Integrated software for image catching, freezing, processing, and report printing.

✓

Built-in measurement tools for distance, circumference, and area analysis.

Technical Parameters

Lens Resolution	1/4" Super HAD color CCD, 480,000 pixels
Axial Resolution	470 lines; Lens S/N: 50dB
Focus Distance	Standard 100~400mm; Support: 10~1000mm
Output Interface	Video, S-video, PAL
Power Supply	AC220V ±10%, Rated power: 500W

Product Presentation

Frequently Asked Questions

What is the imaging quality of the SY-F003 system?

The system utilizes an imported 1/4" Super HAD color CCD with 480,000 pixels and 470 lines of axial resolution, providing high-definition diagnostic images.

What kind of light source does this colposcope use?

It uses a high-power white LED light source that provides even brightness, better color temperature than halogen lamps, and a long lifespan of up to 100,000 hours.

How many patient records can the system store?

The system features super-large memory storage, allowing for the management and storage of up to 100,000 clinical cases.

Can I perform measurements directly on the screen?

Yes, the software supports multi-way enhanced display and includes professional tools to measure distance, circumference, and area.

What is the magnification capability of the lens?

The lens supports a 1-128x magnification range with continuously variable adjustment for precise viewing of clinical details.
