Medical Waste Autoclave Hospital Waste Autoclave Sterilization Equipments

Customization:	Available
Theory:	Autoclave
Type:	Pressure Steam Sterilization Equipments

Send Inquiry

Product Description

📋 Basic Information

Model NO.:YG

Certification:CE

LCD Display:With LCD Display

Temperature Alarm:Ultra High Temperature Alarm

Data Recording:Information Recording and Printing

Material:Stainless Steel

Application:Hospitals, Pharmaceutical, Scientific Research

Guarantee Time:One Year

Transport Package:Wooden Case

Origin:Jiangsu

HS Code:84778000

Production Capacity:500 Sets/Year

🔬 Product Overview

Medical Waste Autoclave Hospital Waste Autoclave Sterilization Equipments

Application: Suitable for hospitals, pharmaceutical factories, scientific research institutes to sterilize and dry cloths, dresses, metal instruments, culture medium, etc.

🏗️ Structure Features

Vessels designed to China National Standard-GB150.
National Patent door interlock device.
Inflatable seal ring with compressed air.
Integrated PLC and HMI control system.
GMP validation port (16 temperature sensors).
Independent temperature monitoring system.
Steam condenser in exhaust/vacuum line.

⭐ Key Advantages

User-friendly Touch-Screen Operation.
High Precision Pressure Controller.
Real-time Printing of Data and Curves.
Patented Gate Lock Safety Structure.

📊 Main Parameters & Utilities

Parameter	Value	Utility	Requirement
Design Pressure	0.245Mpa	Vacuum	-0.095Mpa
Working Pressure	0.22Mpa	Steam Pressure	0.4-0.6Mpa
Design Temp.	139℃	Tap Water Pressure	0.2-0.3Mpa
Working Temp.	134℃	Compressed Air	0.6-0.8Mpa

📏 Model Specifications

Model	Overall Size (LWH)	Chamber Size (mm)	Steam (kg/c)	Power (Kw)	Water (Kg/c)	Weight (kg)
YG-0.1	82510801600	630400480	15	1	80	380
YG-0.25	89512201720	700600600	20	1.5	150	650
YG-0.36	119512201720	1000600600	25	1.5	150	760
YG-0.6	124513001880	1050680850	30	2	200	1100
YG-0.8	159513001880	1400680850	35	3	250	1300
YG-1.2	169513701960	15007501100	40	3	300	1900
YG-2.5	319513701960	30007501100	75	4.5	450	2800
YG-5	363618002200	340010001500	150	7.5	600	4500

🛠️ After-Sales Service

One-year guarantee for the entire machine.
24-hour technical support availability.
Overseas Engineering: Engineers available for onsite service (travel/lodging by customer).
Maintenance Guidance: Lifetime instruction on machine maintenance with best-price spare parts.
Training Service: Professional training for equipment operators.

📸 Detailed Views

❓ Frequently Asked Questions

What materials can be processed with this autoclave?

The machine is designed for hospital and pharmaceutical use to sterilize cloths, metal instruments, culture media, and various medical wastes.

Does the equipment meet international safety standards?

Yes, the vessels are designed according to the China National Standard-GB150 and the product holds CE certification.

How is the sterilization process monitored?

It features an integrated PLC and HMI system with high-precision pressure controllers and an independent temperature monitoring system. It can also record and print sterilization curves.

What are the door safety mechanisms?

The unit utilizes a national patent door interlock device and national patent sealing technology using an inflatable seal ring with compressed air.

What kind of maintenance support is offered?

We provide a one-year warranty, 24/7 technical support, and lifetime maintenance guidance. Spare parts are provided at cost after the warranty period.

Is validation support available for GMP environments?

Yes, a GMP validation port is provided, allowing for the insertion of up to 16 temperature sensors for validation processes.
