Our MB-C, MB-E, and MB-Y mechanical vacuum boosters are oil-free vacuum pumps that run together with backing pumps for all rough and high-vacuum applications where large pumping speeds are required. These vacuum boosters operate totally contact-free and without sealing fluids such as oil or water in the vacuum chamber. MB-Y vacuum boosters are equipped with a bypass valve.
🔹 Economical: Customizable pumping speed and ultimate vacuum based on specific processes. High pumping efficiency ensures reduced operating costs.
🔹 Safe Operation: Robust design and tried-and-tested engineering. The MB-Y series includes an integrated bypass valve allowing operation at high pressure levels.
| Technical Specification | Unit | MBC0500 Value |
|---|---|---|
| Pumping Speed | m3/h | 500 |
| Ultimate Pressure | mbar(abs) | 1×10-3 |
| Diameter | " | VG63/ISO100 |
| Voltage | V | 320-440 |
| Nominal Motor Rating | Kw | 2.2 |
| Current | A | 3.9/4.0 |
| Nominal Speed | Min-1 | 900/1120 |
| Sound | dB(A) | 68 |
| Oil (max) | L | 4.6/5.0 |
| Weight | Kg | 79.5 |
